Series ZMS
Dual Brine Preparation Systems
Total Capacity
1500 - 4000
Liter (50% Mixing Tank, 50% Storing Tank)
- Two Tank Mixing, Storing, Cooling System: Allows operators to mix and maintain brine at a precise temperature using an innovative two-tank and heat exchanger design, preventing seasonal water temperature fluctuations from affecting product quality. Our dual brine preparation systems use one tank for mixing and a separate tank for storage. This dual tank design allows the next batch to be prepared while mixed brine is held for use, helping reduce delays between batches and support higher-throughput food processing operations.
- Two Turbo Agitator Mixing System: Features two turbo mechanical agitators in the mixing tank for efficient mixing. Capable of integrating with an injector for seamless operation, it ensures a homogenous brine solution in a short time.
- Centrifugal Brine Circulation System:
Equipped with an efficient centrifugal pumps that ensure excellent blending of dry ingredients in water. This also allows for easy transportation of the prepared brine.
- Additional Features: Fitted with a smooth hopper and a vibrating device to facilitate the easy addition of dry ingredients to water, ensuring efficient mixing. Also equipped with an automatic water dosing system to ensure consistent brine preparation.
Our Customers
Why Choose BAK
Durable, Industrial-Grade Construction:
Built entirely from stainless steel for exceptional durability and long-lasting performance in demanding environments.
Advanced Programmable Control Panel:
Intuitive touch screen allows operators to create and store up to 99 custom programs by adjusting variables such as vacuum level, rotation speed, tumbling time, and temperature.
Easy Cleaning and Maintenance:
Thoughtfully designed to make routine cleaning and maintenance straightforward and efficient. Inspection hatches are strategically placed for quick, convenient access.
Technical Information
Applications
NOMA Dual Brine Preparation Systems are designed for preparing brine for the injection of a variety of products such as meats, whole poultry and poultry parts, as well as fish and fish fillets. It is also suitable for use in tumbling/marination as well as any other application for which brine is used.
Options
Automatic water dosing supports repeatable brine preparation with less reliance on manual water adjustments. The optional Brine Dosage System meters prepared brine into downstream equipment, while the optional SCADA Monitoring System gives operators visibility into process parameters and records. Together, these capabilities support more consistent preparation, transfer, and process oversight.
